Please watch the video below on Hitting Calibration.

Steps to Calibrate for Hitting

1. Open the Trackman Baseball App and Connect to Wi-Fi
   • Launch the Trackman Baseball app on your iPad or device.
   • Go to the settings page, or tap the three lines ☰ in the right-hand corner to open the menu.
   • Scroll down and hit the Connect to Trackman button.
   • This links your device to the Trackman’s Wi-Fi.
2. Start Calibration
   • Tap the Calibrate Trackman button.
3. Select Your Session Type
   • A prompt will ask: hitting, pitching, or live AB? Choose the type of session you're doing today.
4. Set Height and Distance
   • Enter your setup details on the height and distance page. Distances range from 8 ft to 24 ft back—plenty of flexibility for different spaces.
   • For a booth setup like this one, use 8 ft distance and 4 ft height.
   • Click Next.
5. Align the Live Camera on Home Plate
   • The live camera view appears with an orange box on home plate.
   • Position the orange box exactly where the device should look for batted balls or incoming pitches.
   • Click Next.
6. Calibrate the Three Points of Home Plate
   • Tap the top left point of home plate
   • Click Next.
   • Tap the top right point
   • Click Next.
   • Tap the bottom point, then Next.
7. Set the Center Line to Second Base.
   • Use your finger on the iPad screen to draw a straight line right up the middle to second base.
   • Click Next.
8. Verify Success
   • If everything's done correctly, you'll see a big green check mark
